SPECIFICATIONS
| Monitor Section |
Picture size W x H |
6.95 inches(diagonal) wide 156.6 mm x 81.6 mm |
||
| Display system | Transparent TN LCD panel | |||
| Drive system | TFT active matrix system | |||
| Number of pixels | 1152000 800H x 480V x RGB |
|||
| Effective pixels | 99.99% | |||
| Pixel arrangement | RGB striped arrangement | |||
| Back lighting | LED | |||
| DVD Section |
D/A Converter | 24Bit | ||
| Audio Decoder | Linear PCM Dolby digital MP3/WMA/AAC/WAV |
|||
| Video Decoder | MPEG1/MPEG2/DivX | |||
| Wow & Flutter | Below Measurable Limit | |||
| Frequency response | 96k Sampling | 20 – 22,000 Hz | ||
| 48k Sampling | 20 – 22,000 Hz | |||
| 44.1k Sampling | 20 – 20,000 Hz | |||
| Total harmonic distortion 1kHz | 0.010% | |||
| Signal to Noise ratio | 99dB(DVD-Video 96k) | |||
| Dynamic range | 99dB(DVD-Video 96k) | |||
| DISC Format | DVD-Video/VIDEO-CD/CD-DA | |||
| Sampling frequency | 44.1kHz/48kHz 96kHz |
|||
| Quantifying bit number | 16/20/24bit | |||
| USB I/F Section |
USB Standard | USB2.0 High Speed | ||
| Compatible Devices | Mass storage class | |||
| File System | FAT 16/32 | |||
| Maximum Power Supply Current | DC5V(DC logo) 1.5A | |||
| D/A Converter | 24bit | |||
| Audio Decoder | MP3/WMA/AAC/WAV | |||
| Video Decoder | MPEG1/MPEG2/DivX | |||
| Bluetooth Section |
Technology | Bluetooth V3.0 | ||
| Frequency | 2.402 – 2.480 GHz | |||
| Output Power | +4dBm (MAX),0dBm (AVE) Power Class 2 | |||
| Maximum Communication range | Line of sight approx.10m(32.8ft) | |||
| Audio Codec | SBC/AAC | |||
| Profile | HFP(Hands Free Profile) 1.6 A2DP(Advanced Audio Distribution Profile) 1.3 AVRCP(Audio/Video Remote Control Profile) 1.5 GAP(Generic Access Profile) PBAP(Phonebook Access Profile) 1.2 SDP(Service Discovery Profile) SPP(Serial Port Profile) 1.2 |
|||
| FM | Frequency range (Frequency step) |
87.5 MHz – 108.0 MHz (50 kHz) |
||
| Usable sensitivity S/N:26 dB |
8.2dBf 0.71 μV / 75 Ohms |
|||
| Quieting sensitivity S/N:46 dB |
17.2 dBf 2.0 μV / 75 Ohms |
|||
| Frequency response (±3.0 dB) | 30 Hz – 15 kHz | |||
| S/N (dB) | 64 dB(MONO) | |||
| Selectivity | Over 80 dB(±400 kHz) | |||
| Stereo separation | 40 dB(1 kHz) | |||
| AM | Frequency range (Frequency step) |
LW:153 – 279kHz MW:531 – 1611kHz (9kHz) |
||
| Usable sensitivity | MW … 28.5μV / LW … 45μV | |||
| Video | Color system of external video input | NTSC/PAL | ||
| External video input level (RCA jack) | 1Vp-p / 75Ohms | |||
| External video input level (mini jack) | 1Vp-p / 75Ohms | |||
| External audio max input level (RCA jack) | 2V / 25kOhms | |||
| External audio max input level (mini jack) | 2V / 25kOhms | |||
| Video Input level (RCA jacks) | 1 Vp-p / 75 Ohms | |||
| Video Output level (RCA jacks) | 1Vp-p / 75Ohms | |||
| Analog RGB input | 0.7Vp-p/75Ohms | |||
| Audio | Maximum Power (Front&Rear) | 50Wx4 | ||
| Full Bandwidth Power (Front&Rear) | 22Wx4 (at less than 1%THD) |
|||
| Preout level(V) | 4V / 10kOhms | |||
| Preout impedance(Ω) | =< 600 Ohms | |||
| Speaker Impedance(Ω) | 4-8 Ohms | |||
| Equalizer | BAND | 13Band | ||
| Frequency(Hz) | 62.5/100/160/250/400/630/1k/1.6k/2.5k/4k/6.3k/10k/16k | |||
| Gain | -9/-8/-7/-6/-5/-4/-3/-2/-1/0/1/2/3/4/5/6/7/8/9 [dB] | |||
| Q factor | 1.35/1.5/2.0 | |||
| 2Way X’Over | Tweeter | Frequency(Hz) | 1k/1.6k/2.5k/4k/5k/6.3k/8k/10k/12.5k | |
| Gain | -8/-7/-6/-5/-4/-3/-2/-1/0 [dB] | |||
| Front (HPF) | Frequency(Hz) | Through/30/40/50/60/70/80/90/100/120/150/180/220/250 | ||
| Slope | -6/-12/-18/-24 [dB/Oct.] | |||
| Gain | -8/-7/-6/-5/-4/-3/-2/-1/0 [dB] | |||
| Rear (HPF) | Frequency(Hz) | Through/30/40/50/60/70/80/90/100/120/150/180/220/250 | ||
| Slope | -6/-12/-18/-24 [dB/Oct.] | |||
| Gain | -8/-7/-6/-5/-4/-3/-2/-1/0 [dB] | |||
| SW (LPF) | Frequency(Hz) | 30/40/50/60/70/80/90/100/120/150/180/220/250/Through | ||
| Slope | -6/-12/-18/-24 [dB/Oct.] | |||
| Phase | Normal/Reverse | |||
| Gain | -8/-7/-6/-5/-4/-3/-2/-1/0 [dB] | |||
| Position | Front / Rear /Subwoofer Delay | 0 – 610cm (2.0cm Step) | ||
| Gain | -8 to 0dB | |||
| Subwoofer Level | -50 to +10dB | |||
| General | Operating voltage | 14.4V(10.5V to 16V) | ||
| Maximum Current consumption | 10A | |||
| Installation Dimensions WxHxD | 178mm x 100mm x 162mm | |||
| Operational temperature range | -10°C to +60°C | |||
| Weight | Main unit | 2.3Kg | ||
S.R.P. Php 25,000.00
Free installation. Credit cards accepted.
Option : w/ INAV navigation module Php 29,999.00
S.R.P. w/ INAV navigation module Php 35,000.00
